Vivi IP
LED Downlight
Light Source
Seoul SunLike COB
Material
AL + PC Reflector
Color Temperature
2700K
3000K
4000K
5000K
CRI
97
MacAdam Ellipse
3-Step
Beam Angle
30°
50°
Degree of Protection
IP65
TECHNICAL SPECIFICATIONS
| Article No. | LED | P(W) | CC(mA) | Voltage(V) | Angle(°) | CCT(K) | CRI | Flux(lm) |
|---|---|---|---|---|---|---|---|---|
| VV-8-50-27-97 | SunLike COB | 7.6 | 200 | 37 | 50 | 2700 | 97 | 400 |
| VV-8-50-30-97 | SunLike COB | 7.6 | 200 | 37 | 50 | 3000 | 97 | 412 |
| VV-11-50-27-97 | SunLike COB | 10.8 | 300 | 36 | 50 | 2700 | 97 | 630 |
| VV-11-50-30-97 | SunLike COB | 10.8 | 300 | 36 | 50 | 3000 | 97 | 650 |
| VV-13-50-27-97 | SunLike COB | 12.8 | 350 | 36 | 50 | 2700 | 97 | 720 |
| VV-13-50-30-97 | SunLike COB | 12.8 | 350 | 36 | 50 | 3000 | 97 | 740 |
TECHNICAL DRAWINGS
If the specifications do not meet your expectation, you could leave a message for custom services. We provide lighting solutions and pricing within a few days. It is free of charge before entering the prototyping process.
